Pilot Pro Series
The Pilot Pro Series is the flagship of fine-pitch rental LED displays, crafted for high-end productions where visuals can’t compromise. Its thoughtful engineering makes every stage of use easier — from one-handed installation with single-press module replacement to universal hanging and stacking systems for versatile setups. Triple-lock splicing ensures precise flatness across panels, while dual backup systems guarantee stability even under demanding conditions.
Where creativity meets reliability, Pilot Pro stands out. It supports curved, 90°, and staggered splicing, plus mixed configurations with E-Swan and E-Corner to unlock truly dynamic designs. RobustFix, HOB, and Mini LED technologies add an extra layer of protection against collisions, making it as durable as it is impressive. With superior fine-pitch clarity and camera-ready visuals, Pilot Pro is the ultimate choice for XR applications, virtual studios, and premium live events.
Features
- Fine-pitch LED panels for premium rentals
- Easy one-handed installation with quick-swap modules
- Universal hanging & stacking system
- Triple-lock splicing for perfect flatness
- Double backup for stable operation
- Mixed splicing with E-Swan and E-Corner
- Optional RobustFix / HOB / Mini LED for extra protection
- Designed for XR applications & high-end productions
Handy& Easy Installation Ever
Considerate product detail design enables speedy one-handed operation
Integrated central box allows one press for fast replacement
Shape Your LED Wall As You Want
Pilot Pro enables curved,90° splicing staggered and 90° splicing for more creative shapes
Mixed Splicing for More Possibilities
Support mixed splicing with E-Swan and E-Corner to create more incredible stage magics.
Ultra-High Protection
Optional RobustFix / HOB / Mini LED technologies offers extra anti-collision protection
Higher Flatness
Pilot Pro ensures higher flatness with its triple locks for left-right flat splicing
Dual Installation Solution
Pilot Pro adopts universal hanging bars and stacking bars
Specification
| Model | Pilot Pro1.5 | Pilot Pro1.9 | Pilot Pro2.6 | Pilot Pro2.9 | Pilot Pro3.9 |
|---|---|---|---|---|---|
| Pixel Pitch (mm) | 1.5 | 1.9 | 2.6 | 2.9 | 3.9 |
| Panel Size W*H*D (mm) | 500*500*73 | ||||
| Panel Resolution (Pixel) | 320*320 | 256*256 | 192*192 / 192*384 | 168*168 / 168*336 | 128*128 / 128*256 |
| Panel Material | Die-casting Aluminum | ||||
| Panel Weight (Kg/pc) | 8 / 13 | ||||
| Brightness (nits) | 900-1000 | 900-1000 | 900-1500 | 900-1000 | 900-1000 |
| Serviceability | Rear | ||||
